Product name: Tealth fiber optic internal irrigation air motor 6 holes

Order Code: MIF-01C

Water spray: Internal irrigation


Light: Fiber optic

Connector: ISO strandard 6 holes, E-type

Separated air tube & water pipe, perfect cooling system.


Fiber optic air motor Features:

1. Superior FKM material O ring,better autoclave sterilization

2. Exterior channel water spray systerm

3. Exquistie electroplate appearance

4. Forward and reverse options

[Handpiece inserting & removal]

Inserting

Insert the E-type handpiece onto the motor and turning all the way until it click to stop.

Removal

Grip both handpiece and motor respectively, pulling and separating.

[Forward/Reverse Rotation]

1) Forward Rotation: Turn the FWD/REV change ring to“F”.

2) Reverse Rotation: Turn the FWD/REV change ring to “R”.

3) When the FWD/REV change ring is positioned in the middle of “F” and “R”, the drive air is interrupted and the motor does not rotate.

4) When FEW/REV change ring is positioned in F or R, the rotation speed is maximum.

[Maintenance & Care]

After each treatment, sterilizing handpiece in autoclave according to the following steps:

1. Remove the bur, use brush to clean handpiece, then cleaning outside of handpiece with alcohol solution.

2. Lubricate handpiece.

3. Package into autoclaving pouch.

4. Autoclave the handpiece for 12 min at 135℃.

5. Dental handpieces cannot be soaked in a disinfectant with acidic liquid. it will seriously damage the bearings and handpiece internal components

6. Do not use an ultrasonic cleaner to clean the dental handpiece.

7. It is not recommended to repair the dental handpiece by little experience person. For repairing, please return to the factory or send to the designated after-sales service maintenance office.
